V8000 Series Test Modules

V8000 Series Test Modules,Network Testing Device,Lan Network Checker

Network Testing Device

Lan Network Checker

V8000 Series Test Modules deliver complete network protocols testing and emulating functionality on BigTao series test platform. V8000 Series may meet the test requirements of all kinds of networking devices in each stage of R & D, experiment , quality control, performance monitoring and production line.

With support of larger number of streams, higher port density and larger traffic capture memory V8000 Series offer a best cost-effective test solution.

V8000 Series support a full IPv4/IPv6 stack. Each port can generate 64 streams with up to 4 variable domains per stream and simulate hundreds of thousands of interfaces and tens of millions of realistic connections.

With plenty of protocol templates and customizable packet payload and rate, V8000 Series can provide complex protocol test and emulation.

V8000 Series are supported in high performance chassis of BigTao200, BigTao6000 and BigTao12000, providing accurate chassis-to-chassis synchronization.

KEY FEATURES

Support SFP+ on 10G ports

Support line-rate traffic generating and analysis

Integrated IPv4 and IPv6 stack, support layer 2-3 network testing

Support a variety of protocols emulation including RIP, OSPF, ISIS, BGP, IGMP, PPPoE , DHCP, etc.

Accurate and dynamic data rate regulation based on port and stream

Line-rate traffic capture with support of massage editing, filtering and searching

Embedded PC running Windows XP for separately operating

Multi-user login with easy remote access via a network

Support customized error packet generation

Graphical user interface for configuration, data capture and real-time analysis

Test suit based on RFC2544, RFC2889 and RFC3918

SPECIFICATION LIST

Model	V8000 Series
Port Number	Up to 8 x 10G ports per module
Port Rate	10Gbps SFP+/RJ45
Physical	Status Indicators: Tx/Rx Weight: 0.6kg Size: 271mm x 35.5mm x 180mm Peak power requirement: 48W Max
Traffic Generation	Traffic generating based on port and stream, per port have up to 256 different streams Each stream provide up to 4 saltus step domain Accurate data rate regulation based on port and stream, support dynamic data rate regulation Each stream is capable of generating packets of IPv4, IPv6, TCP, UDP, TCP6, UDP6, Ping, IGMP, ARP, etc. Each stream support multiple levels of VLAN and MPLS Signature block is optional in each stream Each stream supports user-defined packets
Traffic Statistics	Statistics results can be displayed in the form of data table and chart Each port can receive up to 1024 streams Traffic statistics based on streams: TX/RX frame count, TX/RX rate count, RX frame Sequence miss count, RX frame IP payload check errors count, Maximum, minimum and average SF latency count, Maximum, minimum and average CT latency Traffic statistics based on ports: TX/RX frame count, TX/RX stream count, TX/RX rate count, RX frame IP header checksum errors count, RX frame FCS errors count, frames through user-defined filters count
Traffic Capture	RX data frame capture TX/RX control frame capture Frame capture based on filter templet Decode hundreds of protocols Support captured frame search according to specific conditions Intuitive display of frames' features such as source IP address, destination IP address, type of protocol and etc.
Protocol Emulation	Integrated IPv4 and IPv6 dual stack, support ARP, NDP, Ping Each port can simulate tens of thousands of interfaces and support sub-interfaces Each port can simulate tens of millions of realistic connections Protocol emulation on RIPv2,RIPng,OSPFv2,OSPFv3,ISISv4,ISISv6,BGP4,PPPoE Client ,DHCP Client,IGMPv2,IGMPv3,GMRP,802.1x,LDP and 802.3ah
Transmitting mode	Continuous, Single burst, Multi burst, Time burst and Serialized
Software Support	TeleExplorer test system, Test suit of RFC 2544/RFC 2889/RFC3918, TeleATT – automated Test system for product line
Others	Easy-to-use graphical user interface Support C++, C# and TCL API for customizing tests

MODULE CLASSIFICATION

Module Name	Ports Per Module	Connecter Type	Single Rate
V6016C	16	10/100/1000M RJ45 Copper	10/100/1000 Mbps
V6016F	16	1000M SFP Fiber	1000 Mbps
V6016M	8+8	10/100/1000M RJ45 Copper and 100/ 1000M SFP Fiber	10/100/1000 Mbps and 1Gbps
V6008C	8	10/100/1000M RJ45 Copper	10/100/1000 Mbps
V6008F	8	1000M SFP Fiber	1000 Mbps
V6008M	4+4	10/100/1000M RJ45 Copper and 100/ 1000M SFP Fiber	10/100/1000 Mbps and 1Gbps
V6004C	4	10/100/1000M RJ45 Copper	10/100/1000 Mbps
V6004F	4	1000M SFP Fiber	1000 Mbps
V8008F	8	10G SFP+ Fiber	10 Gbps
V8004F	4	10G SFP+ Fiber	10 Gbps
V8002F	2	10G SFP+ Fiber	10 Gbps
V9002F	2	40G QSFP+ Fiber	40 Gbps
